ELORRY 0.8T mini excavator
ELORRY 0.8T mini excavator
ELORRY 0.8T mini excavator
ELORRY 0.8T mini excavator
ELORRY 0.8T mini excavator
ELORRY 0.8T mini excavator
ELORRY 0.8T mini excavator
ELORRY 0.8T mini excavator
Operating Weight:
0.8TON
Power:
7.2KW
Max.Torque:
26.8N.m

ELORRY 0.8T mini excavator

With its unique advantages of compactness, flexibility, versatility and efficiency, the 0.8T mini excavator is increasingly becoming the ideal machine for earthmoving applications, and user demand is expanding.
Share:
Product Details
Automobile and construction machinery manufacturers

0.8T mini excavator Crawler excavator is a kind of compact excavator, excavator boom swinging, your work, suitable for different directions mining hydraulic pilot operating system, rubber tracks, with a broken pipe system, adopts the forerunner of the hydraulic servo system operation, the machine can change the orbit by rubber to steel, cabin from open to closed. Make sure it works in different working environments and conditions.

technical parameter
product technical parameter
CHANGCHAI Specification
Engine Model 192FAM
Engine Type Forced Air-Cooled, Direct Injection, Vertical
Number Of Cylinders 1
Combustion Chamber Form Direct Injection
Bore Stroke 92×75mm
Displacement 0.499L
Rated Power 7.5kw/3600r/min
Max.Torque 26.8N.m
Max.Torque Point Speed 2400r/min
Injection Mode Direct Injection
Intake mode Naturally Aspirated
Displacement Second Stage
Ignition Mode Compression Ignition
Lubrication Method Pressure Splash Compound
Calibration fuel consumption ≤320g/kw.h
Idle 1300r/min
Compression Ratio 19:1
Engine Weight 55kg
Overall dimension 420mm×440mm×497mm
application
Automobile and construction application
Why Choose ?

Advantages of 0.8T mini excavator
1.Unique structure design

2.Smooth pipeline before operation, the protective cover can protect the pipeline from damage.

3.The moving arm cylinder adopts famous brand

4. All structural parts are finely processed, with high gloss surface and high paint adhesion.
