Overall length（mm） |
12140 |
|
Engine model |
L360 20 |
| |
Overall width（mm） |
2550 |
|
manufacturer |
Cummins made in China |
| Overall specification |
Overall height（mm） |
3850 |
|
Engine position |
Front |
| Body inside height（mm） |
1940 |
Engine |
Engine Type |
6 cylinders in-line, with intercooler, |
turbocharged |
| Wheel base（mm） |
6300 |
Max power(kw) |
264 |
|
| Front/rear （mm） |
overhang |
2340/3500 |
Max torque(N.m) |
1480 |
|
| Approach/departure（º） |
11月9日 |
Displacement(L) |
8.9 |
| First step height（mm） |
480 |
Bore/stroke |
mm |
114X144.5 |
| Max G.V.W.kg |
18500 |
fuel |
|
Euro II |
| Seats capacity (person） |
64+1 |
Steering position |
|
Left hand drive |
|
| Max. speed |
120km/h |
|
| |
|
|
|
|
|
|
| Items |
|
Standard Equipments |
|
Options |
| Chassis specification |
Manufacturer |
Made by Zhongtong |
|
|
| Gear box |
FAST 6DS150T |
|
|
| Clutch |
Single, dry, Coil spring, Ø430 |
|
|
| Front axle |
8 Ton |
|
|
| Rear axle |
13 Ton |
|
|
| Suspension |
Multi-Leaf spring Suspension |
|
|
| Steering |
Integral assistant power steering |
|
|
| Brake |
Dual circuit air braking, drum brake |
|
|
| Fuel tank |
500L |
|
|
| Tyre |
315/80R22.5 Double coin |
|
|
| Battery /dynamo |
2×12V/195Ah / 28V /150A+140A |
|
|
| Others |
Brake slack auto adjuster, Electric Retarder, ABS |
|
|
| Bus specification |
Body construction |
semi-Integral body , flat floor |
|
|
| Interior trim |
Full soft interior trim |
|
|
| Door & door pump |
Front & middle aluminum outside swing door; anti-clamp door pump, front door with remote control lock, driver door. |
|
|
| Window |
Sliding side windows, rear window steel panel covered, front rubber-laminated windscreen with 2-piece glass, |
|
|
| Rear mirror system |
Manual rearview mirror, reverse view 6” LCD monitor |
|
|
| A/C system |
30000Kcal/h Bitzer compressor |
|
|
| Heating system |
No |
|
|
| Video system |
Hard disc player, 3 LCD front 22’’ and 2 middle 17’’ |
|
|
| Lamps |
New type combination lamp both in front and rear |
|
|
| Wiper |
Luxury wiper |
|
|
| Luggage door |
Steel panel overturning opening door |
|
|
| Seat |
Adjustable headrest |
seats |
with |
USB,3+2 |
layout, |
Driver |
seat |
with |
|
|
| Paint |
High quality paint |
|
|
|
|
|
|
|
|
| |
Double inner luggage rack, air horn, windscreen sun visor, side |
|
|
| |
Others |
window curtain, skid proof floor leather, Stainless steel |
|
|
| |
|
decoration cover, Compressor type refrigerator,WI-FI |
|
|
